the g12 receiving card is a receiving device for displaying data in the control system of the led display screen, which is used to convert the received data into the control signal of the module.
-
- functional characteristics
support upto 1/32 scan
single card maximum support 1024x256 pixels, 1,024 single-point color correction
two fan speed monitoring
temperature monitoring
humidity monitor
smoke monitor
ce-emc standards in line with eu
year of production: 2020
- interface signal definition
|
|
|
-
- 12 pcs 16p standard hub75 interface (jh1-jh12)
the definition is as follows：
|
pin |
definition |
pin |
definition |
|
1 |
r0 |
2 |
g0 |
|
3 |
b0 |
4 |
gnd |
|
5 |
r1 |
6 |
g1 |
|
7 |
b1 |
8 |
e |
|
9 |
a |
10 |
b |
|
11 |
c |
12 |
d |
|
13 |
clk |
14 |
lat |
|
15 |
oe |
16 |
gnd |
description: e signal can be used as blanking control foot when the screen scan is less than 16, and e signal when the screen scan is larger than 16.
